CD293 焊针式 85°C

VDC(Surge Voltage)Code

Rated Capacitance

Max ESR 20℃,120HZ

Typ ESR 20℃,120HZ

Rated Ripple Current 85℃,120HZ

size φ DXL



Part No.

(V)

( μF)

(mΩ)

(mΩ)

(Arms)

(㎜)

-

400(450)
2G

220

905

724

1.1

22×50

ECS2GBZ221M10220050

905

724

1.2

25×40

ECS2GBZ221M10250040

905

724

1.2

30×35

ECS2GBZ221M10300035

270

737

590

1.3

25×45

ECS2GBZ271M10250045

737

590

1.4

25×50

ECS2GBZ271M10250050

737

590

1.5

30×40

ECS2GBZ271M10300040

330

603

483

1.6

35×30

ECS2GBZ331M10350030

603

483

1.7

30×45

ECS2GBZ331M10300045

390

511

409

1.8

35×35

ECS2GBZ391M10350035

511

409

1.8

30×50

ECS2GBZ391M10250045

470

424

339

2.1

30×50

ECS2GBZ471M10300050

424

339

2.1

35×45

ECS2GBZ471M10350045

560

356

285

2.3

35×50

ECS2GBZ561M10350050

680

293

235

2.6

35×50

ECS2GBZ681M10350050

820

243

195

2.8

35×55

ECS2GBZ821M10350055

243

195

2.8

35×60

ECS2GBZ821M10350060

1000

199

160

3.0

35×70

ECS2GBZ102M10350070

450(500)
2W

220

905

724

1.2

22×50

ECS2WBZ221M10220050

905

724

1.3

30×40

ECS2WBZ221M10300040

905

724

1.3

35×30

ECS2WBZ221M10350030

270

737

590

1.4

30×45

ECS2WBZ271M10300045

737

590

1.5

35×35

ECS2WBZ271M10350035

330

603

483

1.7

30×45

ECS2WBZ331M10300045

603

483

1.7

30×50

ECS2WBZ331M10300050

390

511

409

1.9

35×45

ECS2WBZ391M10350045

470

424

339

2.2

35×50

ECS2WBZ471M10350050

560

356

285

2.5

35×50

ECS2WBZ561M10350050

680

293

235

2.9

35×60

ECS2WBZ681M10350060

820

243

195

3.5

35×70

ECS2WBZ821M10350070



CD294  焊针式 105°C

VDC(Surge Voltage)Code

Rated Capacitance

Max ESR 20℃,120HZ

Typ ESR 20℃,120HZ

Rated Ripple Current 105℃,120HZ

size φ DXL



Part No.

(V)

( μF)

(mΩ)

(mΩ)

(Arms)

(㎜)

-

400(450)
2G

220

905

471

0.87

25×45

ECS2GBW221M10250045

905

471

0.96

30×35

ECS2GBW221M10300035

270

737

383

0.94

25×50

ECS2GBW561M10250050

737

383

0.95

30×40

ECS2GBW271M10300040

737

383

0.91

35×30

ECS2GBW271M10350030

330

603

314

1.11

30×45

ECS2GBW331M10300045

603

314

1.13

35×35

ECS2GBW331M10350035

390

510

265

1.15

30×50

ECS2GBW391M10300050

510

265

1.26

35×40

ECS2GBW391M10350040

470

424

220

1.31

35×40

ECS2GBW471M10350040

424

220

1.31

35×45

ECS2GBW471M10350045

560

355

185

1.48

35×50

ECS2GBW561M10350050

680

293

205

1.68

35×50

ECS2GBW681M10350050

820

243

170

1.9

35×60

ECS2GBW821M10350060

1000

199

139

2.58

35×60

ECS2GBW102M10350060



CD135 螺栓式 85°C

UR
(Surge Voltage)
Code

Rated Capacitance

Max ESR
20℃,
120HZ

Typ ESR
20℃,
120HZ

Rated Ripple Curren
85℃,
120HZ

size φ DXL



Part No.

(V)

( μF)

(mΩ)

(mΩ)

(Arms)

(㎜)

-

400(450)
2G

330

868

248

1.5

36×53

ECG2GBP331MA053Y

390

735

208

2

36×83

ECG2GBP391MA083Y

470

610

178

2.2

36×83

ECG2GBP471MA083Y

560

512

145

2.4

36×83

ECG2GBP561MA083Y

680

421

119

2.8

36×100

ECG2GBP681MA100Y

820

349

98.5

3.1

36×100

ECG2GBP821MA100Y

1000

287

82.3

3.5

51×75

ECG2GBP102MC075Y

1200

239

67.5

3.8

51×75

ECG2GBP122MC075Y

1500

191

58

4.7

51×96

ECG2GBP152MC096Y

1800

159

47.2

5.2

51×96

ECG2GBP182MC096Y

2200

130

34.8

6.4

51×120

ECG2GBP222MC120Y

2700

107

33.2

7

64×96

ECG2GBP272MD096Y

3300

86.8

31.2

8.2

64×115

ECG2GBP332MD115Y

3900

73.5

25.1

9.4

64×115

ECG2GBP392MD115Y

3900

73.5

25.1

9.4

64×130

ECG2GBP392MD130Y

4700

61

23.7

10.4

77×115

ECG2GBP472ME115Y

5600

51.2

19

11.9

77×130

ECG2GBP562ME130Y

6800

42.1

15.5

14.1

77×155

ECG2GBP682ME155Y

8200

34.9

13.5

16.4

90×157

ECG2GBP822MF157Y

10000

28.6

11.1

18.3

90×157

ECG2GBP103MF157Y

12000

23.9

9.8

21.8

90×196

ECG2GBP123MF196Y

15000

19.1

8

26.3

90×236

ECG2GBP153MF236Y



CD136 螺栓式 105°C

UR
(Surge Voltage)
Code

Rated Capacitance

Max ESR
20℃,120HZ

Typ ESR
20℃,120HZ

Rated Ripple Current 105℃,120HZ

size φ DXL



Part No.

(V)

( μF)

(mΩ)

(mΩ)

(Arms)

(㎜)

-

400(450)2G

1000

215

82

2.5

51×75

ECG2GPK102MC075Y

1200

179

70

3

51×96

ECG2GPK122MC096Y

1500

143

49

3.6

51×115

ECG2GPK152MC115Y

1800

119

39

4.1

51×130

ECG2GPK182MC130Y

2200

98

30

4.5

64×96

ECG2GPK222MD096Y

2700

80

22

5.3

64×115

ECG2GPK272MD115Y

3300

65

20

6.2

64×130

ECG2GPK332MD130Y

3900

55

18

7.2

64×155

ECG2GPK392MD155Y

3900

55

18

6.8

77×115

ECG2GPK392ME115Y

4700

46

13

8.7

64×195

ECG2GPK472MD195Y

4700

46

13

7.8

77×130

ECG2GPK472ME130Y

5600

38

12

9.6

64×195

ECG2GPK562MD195Y

5600

38

12

9.2

77×155

ECG2GPK562ME155Y

6800

32

11

10.7

90×157

ECG2GPK682MF157Y

8200

26

10

11.8

90×157

ECG2GPK822MF157Y

10000

22

9

14.1

90×196

ECG2GPK103MF196Y



CD138 螺栓式 长寿命高可靠性

UR
(Surge Voltage)
Code

Rated Capacitance

Max ESR
20℃,120HZ

Typ ESR
20℃,120HZ

Rated Ripple Current 105℃,120HZ

size φ DXL



Part No.

(V)

( μF)

(mΩ)

(mΩ)

(Arms)

(㎜)

-

400(450)2G

1000

215

82

5.0

51×83

ECG2GPC102MC083Y

1200

179

70

5.5

51×83

ECG2GPC122MC083Y

1500

143

50

6.7

51×96

ECG2GPC152MC096Y

1800

119

40

7.4

51×96

ECG2GPC182MC096Y

2200

98

28

9.2

51×130

ECG2GPC222MC130Y

2700

80

23

9.9

64×96

ECG2GPC272MD096Y

3300

65

21

11.8

64×115

ECG2GPC332MD115Y

3900

55

19

13.5

64×130

ECG2GPC392MD130Y

4700

46

15

14.9

77×115

ECG2GPC472ME115Y

5600

39

14

17.0

77×130

ECG2GPC562ME130Y

6800

32

13

20.20

77×155

ECG2GPC682ME155Y

8200

26

12

23.50

90×157

ECG2GPC822MF157Y

10000

22

10

25.90

90×157

ECG2GPC103MF157Y

12000

18

8

31.00

90×196

ECG2GPC123MF196Y

15000

14

6

37.50

90×236

ECG2GPC153MF236Y
